High-Efficiency Capacitor Stand Fan Motor – Quiet, Durable, Reliable for Pedestal Fans
Introduction to Capacitor Stand Fan Motor
The capacitor stand fan motor is an essential component for modern pedestal fans, designed to deliver quiet, durable, and energy-saving performance. This capacitor stand fan motor ensures smooth oscillation, reliable airflow, and long-lasting service life, meeting the demands of both residential and commercial environments. With a focus on high efficiency, the capacitor stand fan motor is the perfect choice for upgrading or replacing existing stand fan replacement motors.
Item | Specification |
Product Name | Single-phase Capacitor-run AC Induction Gear Motor |
Model | |
Rated Voltage | 220–240V AC |
Frequency | 50/60Hz |
Power | 15W / 20W / 30W |
Capacitor | 1.5–2.0μF / 450VAC |
Insulation Class | Class B / F optional |
Protection Rating | IP20 / IPX0 (customizable) |
No-load Speed | ~1200RPM (4 poles at 50Hz) |
Gear Ratio | 1:50 / 1:60 / customizable |
Output Speed | 10–30 RPM (depends on ratio and frequency) |
Output Shaft Diameter | Ø8mm (D-cut / round) |
Output Shaft Length | 25mm (customizable) |
Housing Material | Stamped Steel |
Gear Material | POM / Nylon / Metal options |
Shaft Material | Carbon Steel / Stainless Steel options |
Certifications | CE / CCC / RoHS / TUV / CQC (Capacitor Certification) |
Typical Applications | Fan Oscillation Drive, Fan Head Swing Motor, Appliance Drive |
Key Features and Benefits of Stand Fan Replacement Motor
The stand fan replacement motor is engineered for superior performance. This quiet stand fan motor operates at low noise levels, ideal for bedrooms, offices, and living rooms where silent airflow is essential. With energy-saving pedestal fan motor design, power consumption is optimized without sacrificing performance. Durable capacitor fan motor construction ensures resistance to wear, heat, and humidity, extending service life and reducing maintenance costs.
The capacitor stand fan motor offers multiple power options (15W, 20W, 30W) with custom shaft lengths and gear ratios to match various fan designs. Certified with CE, CCC, RoHS, TUV, and CQC, the capacitor stand fan motor guarantees compliance with international quality standards.
Advanced Engineering for Quiet Stand Fan Motor
Quiet stand fan motor performance is achieved through precision balancing and high-grade bearings. The capacitor stand fan motor uses quality materials like stamped steel housings, carbon steel or stainless steel shafts, and customizable gear materials (POM, nylon, or metal) for smooth, silent operation. This engineering ensures the energy-saving pedestal fan motor delivers stable rotation speeds (10–30 RPM output), perfect for consistent airflow.
Manufacturers rely on this durable capacitor fan motor for consistent production runs. Daily factory output exceeds 1000 units, guaranteeing quick delivery even for bulk orders. With ample stock and flexible customization, the capacitor stand fan motor is ready to meet OEM and ODM requirements worldwide.
Applications and Customization Options for Energy-Saving Pedestal Fan Motor
The energy-saving pedestal fan motor is widely used in pedestal fans for home cooling, commercial ventilation, and appliance oscillation drives. The capacitor stand fan motor’s output speed and shaft length can be customized to suit different fan head designs, from traditional large-blade floor fans to compact, modern oscillating models.
Stand fan replacement motor options include round or D-cut output shafts for compatibility with different fan blade hubs. The quiet stand fan motor design ensures reduced noise pollution, making it ideal for hospitals, schools, and hotels seeking a peaceful environment. Durable capacitor fan motor construction also resists corrosion and mechanical wear, maximizing service life in demanding climates.
Manufacturing and Quality Assurance of Durable Capacitor Fan Motor
Manufacturing of the capacitor stand fan motor combines automated winding, precision assembly, and rigorous testing. Every stand fan replacement motor undergoes electrical performance verification, insulation resistance checks, and noise-level testing to ensure each quiet stand fan motor meets strict quality targets.
Energy-saving pedestal fan motor production lines can support both high-volume orders and small-batch prototyping. This flexibility helps brands and distributors maintain reliable supply chains. With certifications like CE, CCC, RoHS, TUV, and CQC, the durable capacitor fan motor is trusted by global fan manufacturers for its proven safety and performance.
Why Choose This Capacitor Stand Fan Motor?
Choosing the capacitor stand fan motor means investing in quiet stand fan motor performance, energy efficiency, and durability. The stand fan replacement motor is designed for easy installation, reliable operation, and minimal maintenance. Whether used in household pedestal fans or commercial appliances, the energy-saving pedestal fan motor helps reduce power bills and extend product lifespan.
For OEM partners and distributors, this durable capacitor fan motor offers customizable solutions with short lead times and stable pricing. Large daily output capacity ensures consistent supply, while a dedicated engineering team supports design optimization for any application.
